Beta-Barium Borate (BBO) Crystal

BBO crystal (β-Barium Borate, β-BaB?O?), a trigonal non-centrosymmetric nonlinear optical crystal, is renowned for generating 2nd–5th harmonics of Nd:YAG lasers with efficiencies up to 70% (SHG, 532 nm), 60% (THG, 355 nm), 50% (FHG, 266 nm), and a record 200 mW at 213 nm (FFHG). Its superior performance stems from a broad transparency range (189–3500 nm), high nonlinear coefficient (d?? = 2.6 pm/V at 1064 nm→532 nm), low photorefractivity, and non-hygroscopicity, making it critical for UV lithography, laser micromachining, and medical optics.

Hot Tags : BBO crystal β-Barium Borate crystal BBO nonlinear optical crysta β-BBO crystals Beta barium borate crystal Β barium borate crystal
Read More
Lithium Triborate (LBO) Crystal

LBO Crystal, short for Lithium Triborate Crystal, is a remarkable nonlinear optical crystal. With a chemical formula of LiB?O?, it features a wide transparency range from 155 to 3200 nm, allowing interaction with diverse laser sources. It has a high damage threshold, capable of withstanding intense laser beams without performance degradation, which is crucial for high - power laser applications. LBO Crystal also shows excellent optical homogeneity. It's widely used in frequency doubling, tripling of high - peak - power pulsed lasers, and optical parametric oscillators. Its outstanding properties make it an essential component in optical systems like medical lasers, laser displays, and optical data storage.

Hot Tags : LBO crystal Customized LBO dimensions LBO nonlinear optical crystal frequency doubling LBO Crystal Lithium Triborate (LBO) Crystal Lithium Triborate Crystal
Read More
Potassium Titanyl Phosphate (KTP) Crystal

KTP Crystal is mostly used as nonlinear crystals for frequency doubling of solid-state Nd:YAG crystal or Nd:YVO4 crystal laser, as it has large nonlinear optical coefficients, wide angular bandwidth and small walk-off angle, broad temperature and spectral bandwidth. KTP crystal also has high electro-optic(E-O) coefficient and low dielectric constant, and large figure of merit, these features make it also widely used in electro-optic application.

Hot Tags : KTP crystal KTP nonlinear optical crystal Potassium Titanyl Phosphate (KTP) Crystals KTP frequency doubling crystal High damage threshold KTP KTP (Potassium Titanyl Phosphate)
Read More
Periodically Poled KTP (PPKTP) Crystal

Periodically Poled Potassium Titanyl Phosphate (PPKTP) crystal is a ferroelectric nonlinear crystal with a unique structure, which aids in efficient frequency conversion through Quasi - Phase - Matching (QPM). The crystal is composed of alternating domains with spontaneous polarization of opposite orientations, enabling QPM to correct the phase mismatch in nonlinear interactions. The crystal is suitable for efficient conversion of any nonlinear process within its transparency range.

Hot Tags : PPKTP crystal PPKTP nonlinear optical crystal AR coating PPKTP crystal PPKTP frequency doubling crystal High damage threshold PPKTP crystal Potassium Titanyl Phosphate Crystal
Read More
Lithium Niobate (LiNbO3) Crystal

Lithium Niobate (LiNbO3) is widely used as electro-optic modulator and Q-switch for Nd:YAG, Nd:YLF and Ti:Sapphire lasers as well as modulator for fiber optics, etc. The transverse modulation is mostly employed for LiNbO3 crystal. Also LiNbO3 Crystal is widely used as frequency doublers for wavelength >1um and optical parametric oscillators (OPO) pumped at 1064 nm as well as quasi-phase-matched (QPM) devices.

Hot Tags : Lithium Niobate (LiNbO3) LiNbO? optical properties LiNbO? vs other electro-optic crystals Lithium Niobate (LiNbO3) crystals Lithium Niobate Crystal (LiNbO3 Crystal) Lithium Niobate Wafers
Read More
Periodically Poled LN (PPLN) Crystal

Periodically Poled LN (PPLN) Crystal is formed by fabricating the nonlinear optical crystal lithium niobate (LN) into a periodically reversed domain structure, based on the quasi - phase matching theory (QPM). This unique structural design enables specific optical properties critical for nonlinear optical applications.

Hot Tags : PPLN crystal Periodically Poled LN (PPLN) Crystal PPLN optical properties Periodically-Poled Lithium Niobate Crystal PPLN optical modulator Lithium Niobate (LiNbO3) crystal
Read More
Potassium Dihydrogen / Dideuterium Phosphate (KDP-KD*P) Crystal

Potassium Dihydrogen Phosphate (KDP, KH?PO?) and Potassium Dideuterium Phosphate (KDP, KD?PO?) are tetragonal nonlinear optical crystals widely used for second (532 nm, 60% efficiency), third (355 nm), and fourth harmonic generation (266 nm) of Nd:YAG lasers via type I/II phase matching at room temperature, with KDP offering 75% SHG efficiency and higher damage threshold via deuteration. As electro-optic materials, they feature ultra-high coefficients (r??=23.3 pm/V for KDP), low half-wave voltage (~7.6 kV at 1064 nm), and broad bandwidth (>10 GHz), enabling applications in Pockels cells, modulators, and high-power laser systems like inertial confinement fusion, where KDP’s non-hygroscopicity outperforms KDP in harsh environments.

Hot Tags : KDP and KD*P crystals KDP and KD*P for harmonic generation Potassium Dihydrogen Phosphate (KDP) KDP KD*P Crystal KDP in Nd:YAG lasers KDP/KD*P Crystals
Read More
Calcite (CaCO?) Crystal

Calcite (CaCO?), a trigonal negative uniaxial crystal with extreme birefringence and broad transmission (200 nm–2300nm), is the premier material for visible-near infrared polarizing optics despite its softness (Mohs 3) and hygroscopicity. It enables Glan–Taylor/Thompson polarizers with extinction ratios >10?:1, beam displacers, and UV wave plates, outperforming synthetic crystals like YVO? in the ultraviolet range but requiring AR coatings and humidity control.

Hot Tags : Calcite Crystal Calcium Carbonate Crystal Anisotropic Optical Crystal Calcium carbonate (CaCO3) Crystal Birefringent Crystal Calcite CaCO3 Optical Crystal
Read More
Yttrium Orthovanadate (YVO4) Crystal

The yttrium orthovanadate (YVO4) is a positive uniaxial crystal grown with Czochralski method. It has good mechanical and physical properties and is ideal for optical polarizing components because of its wide transparency range and large birefringence. It is an excellent synthetic substitute for Calcite (CaCO3) and Rutile (TiO2) crystals in many applications including fiber optic isolators and circulators, beam displacers, Glan polarizers and other polarizing optics, etc.

Hot Tags : Yttrium Vanadate (YVO4) Crystal AR-coated YVO? crystal High damage threshold YVO? Non-hygroscopic YVO? Wide transparency range YVO? Large birefringence YVO?
Read More
Alpha-Barium Borate (α-BBO) Crystal

High Temperature form BBO (a-BaB2O4) is a negative uniaxial crystal.It has large birefringence over the broad transparent range from 189 nm to 3500 nm.Recently,MT-Optics has succeeded in growing this crystal into large size.The physical,chemical,thermal and optical properties of a-BBO crystal are similar to those of β-BBO.However,the nonlinear optical properties of a-BBO crystal is vanished due to the centric symmetry with its crystal structure,it is not recommended or NLO processes.

Hot Tags : Barium Borate (α-BBO) Crystal α-BBO crystal Customized a-BBO Crystal Large birefringence α-BBO crystal High-Temperature BBO crystal Alpha-BBO crystal
Read More
Neodymium Doped Gadolinium Orthovanadate (Nd:GdVO4) Crystal

Neodymium doped Gadolinium Vanadate (Nd:GdVO4 crystals) belonging to the tetragonal crystal system, is an excellent ideal laser host material for DPSS (Diode Pumped Solid State) micro/mini lasers. It exhibits remarkable physical, optical, and mechanical properties. In terms of laser performance, Nd:GdVO4 crystals demonstrate higher slope efficiency compared to Nd:YAG crystals. When contrasted with Nd:YVO4 crystals, they possess superior thermal conductivity, enabling more stable operation under high-power conditions, and can achieve higher power output. Moreover, its distinct optical anisotropy facilitates efficient polarization control in laser systems. These characteristics make Nd:GdVO4 crystals highly suitable for applications in compact laser devices, such as medical laser equipment, precision laser processing systems, and advanced scientific research laser setups, where high efficiency and stable performance are critical requirements.

Hot Tags : Nd:GdVO4 in laser systems Neodymium doped Gadolinium Vanadate (Nd:GdVO4) Crystal Nd:GdVO4 laser crystal Nd:GdVO4 Crystals Diode pumped Nd:GdVO4 laser Nd:GdVO4 single crystal
Read More
Neodymium Doped Yttrium Aluminum Garnet (Nd:YAG) Crystal

Nd:YAG crystal is the most widely used solid-state laser material today. It has been used in the "micro/mini" DPSS (Diode Pumped Solid State) laser system to generate high-quality red, green, or blue laser output. The blue laser from Nd:YAG crystal has higher efficiency and is easier to realize than the blue laser from Nd:YVO4 crystal. Nd:YAG crystal is also widely used in military, scientific, medical, and industrial laser systems, high-performance scientific laser systems, laser therapy, cosmetology systems, laser marking, laser drilling, and other laser material processing systems. Notably, Nd:YAG crystal is the best laser material for high-power, high-energy, and Q-switched pulse laser systems. The extensive applications of Nd:YAG crystal in various laser systems stem from its outstanding physical and mechanical properties.

Hot Tags : Nd:YAG crystal Nd:YAG laser crystal Neodymium-doped yttrium aluminum garnet (Nd:YAG) laser crystal Nd:YAG manufacturers Nd:YAG rods 808 nm pumped Nd:YAG
Read More
